Heat Shrinkable Single Fiber Splice Protector For Optical Closures

Brand Name : XXR

Model Number : OFSS-60T

Certification : SGS

Place of Origin : China

MOQ : 50,000 pcs

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 200K pcs/day

Delivery Time : 5-7 days

Packaging Details : 12 pcs/pack

Name : 60mm single fiber splice sleeve

Suitable for : Splice closure

Spec. : 1.2*60 MM

Steel diameter : 1.2MM

Length : 60MM

OD after shrinking : 2.5MM

Ends sealing : Half

Color : Transparent

Contact Now

Heat Shrinkable Single Optical Fiber Splicing Protector Sleeves For Optical Closures

60MM splice sleeve is produced by XXR, who is committed to manufacturing
sorts of fiber sleeves. The company with ten advanced automatic-assembly
equipment is capable to produce hundred and eighty thousand of sleeves
per day and quality guaranteed.

Splice sleeve is also called heat shrinkable tube, made of PE and EVA,
prshrunk at both ends during production.

It's regular sizes are 40mm, 45mm, and 60mm long, the reinforced member
adopts stainless steel with diameter 1.5mm,1.2mm,1.0mm,0.8mm,0.5mm and so on.

Generally, the fiber sleeve is used for fiber splicing in the FTTH & FTTx project.

Function: it is a splicing component for enhancing protection or supporting
positioning of optical fiber splicing. In a word, it is for optical fiber fusion protection.

Application: optical communication field.

Features: parts splicing, enhanced protection, supporting positioning, reliable.

Specification:

Part No. Spec. (mm)

Steel rod

dia.(mm)

Outer tube

L.(mm)

OD after shrinking

(mm)

Inner tube

L.(mm)

ID

(mm)

OFSS-40T 1.5 * 40 1.5 40 3.0 40 ≥1.2
OFSS-45T 1.5 * 45 1.5 45 3.0 45 ≥1.2
OFSS-60T 1.5 * 60 1.5 60 3.0 60 ≥1.2
OFSS-40T 1.2 * 40 1.2 40 2.7 40 ≥1.2
OFSS-45T 1.2 * 45 1.2 45 2.7 45 ≥1.2
OFSS-60T 1.2 * 60 1.2 60 2.7 60 ≥1.2
OFSS-40T 1.0 * 40 1.0 40 2.5 40 ≥1.2
OFSS-45T 1.0 * 45 1.0 45 2.5 45 ≥1.2
OFSS-60T 1.0 * 60 1.0 60 2.5 60 ≥1.2
